Micron stainless steel discharge fluidized plate for powder filteration
Metal Sintered Mesh Filter replacement element
Metal Sintered Mesh Filter
The equipment is installed on the fluidizer at the bottom of the injection tank or inside the fluidizer at the bottom of the pulverized coal bunker.
Orders are confirmed by our team for price, compatibility and delivery.
Verified specifications for confident selection.
Confirm installation requirements against the equipment manual or original documentation.
| Category | Metal Sintered Mesh Filter |
|---|---|
| Equipment System | Sintered Filter Systems |
| Filtration Rating | 3-20um |
The fluidized plate is made of high technology and high performance stainless steel sintered wire mesh. Its characteristics are high temperature resistance, corrosion resistance, high mechanical strength, high rigidity, long service life, high pore precision, uniform airflow distribution and small resistance loss.
The equipment has good fluidization effect and stable performance. It is the key equipment for dense phase transportation.
Easy to adjust the quantity of material transportation, save the gas and reduce the cost.
Fluidized plate can be designed for fixed welding type, movable type (bolt fastening) and other forms.
Technical parameter:
| Medium | Dust and nitrogen (or air) |
| Temperature (℃) | 100 |
| Pressure (MPa) | 1.0、1.6、2.5 |
| Air permeability (L/min.cm2.pa) | (5~8)×10ˉ3 |
Installation Notes
Stop the system and release pressure before removal. Confirm flow direction and sealing surfaces before installation.
Maintenance & Replacement
Replace according to pressure drop or the maintenance schedule. Inspect for leakage and seal damage.
Before Ordering
Confirm medium, flow rate, pressure, temperature, connection and available installation space.
